KX-(130-260-400-500)-DIY Laser Cannon Colored. Handheld (130W-260W-400W-500W). Range (15-50-80-50)m , with fast charging.

Once your order is successfully placed, our team will commence the assembly and testing processes. This meticulous procedure typically requires 3 to 5 business days to ensure product quality and functionality. We sincerely appreciate your patience and understanding as we work to deliver a flawless item to you.

The battery boasts a lifespan of 5 years, featuring a full charge duration of approximately 3 hours and a continuous operational time of 1 hour post-charge. It is capable of intermittent operation for roughly 5 hours. The shipment includes fast charging capabilities. Typically, it is utilized intermittently.

KX500 Product Features

1. Powerful performance: With a large-diameter lens, it can penetrate a blade at 15 meters and burn a cardboard box at 50 meters.

2. No ready stock: Will be shipped after 5 working days of assembly and testing.

3. Configuration: 500W laser power.

4. Large-diameter quartz focusing lens.

5. Voltage display (battery parameters: 46.2V, 10Ah).

6. Temperature display with 45°C power-off protection.

7. Internal full silicone wires, 10S2P configuration.

8. Built-in protective board.

9. Full charge supports 30 minutes of continuous operation.

10. Three fans for cooling, high heat dissipation efficiency.

11. High-power constant current/voltage power supply module maintains high power output even at low battery levels.

12. Red coaxial indicator (industrial-grade high-temperature resistance; slight coaxial deviation is normal and unavoidable).

13. Total weight: 4.5 kg.

Notes

• Not intended as a laser cutter (for toy use only).

• Recommended for: Killing insects (mosquitoes, flies, cockroaches, etc.). The small workshop will not be liable for consequences caused by abnormal use.

1. All lasers of this type require focusing; the spot is blurry (not a dot) at long distances, so long-range penetration or cutting is not suitable.

2. The smallest spot (best for cutting/penetrating) is at ~1 meter; the spot expands as distance increases.

3. No return or refund for no-reason claims; returns/exchanges are allowed for quality issues or unmet performance expectations until satisfied.

Usage Instructions

1. IMPORTANT: Ensure the lens is clean before installing it.

2. Avoid continuous long-time operation (may cause driver overheating); do not shine on highly reflective objects at close range.

3. Two black buttons on the back: top is main power switch, bottom is red dot indicator switch. Press the handle switch after turning on the main power to emit light (NEVER point the lens directly at any object when igniting).

4. Check battery level: ~42V when full, ~35V when charging is needed. The green light turns on when fully charged.

5. Close-range focusing: The shallower the lens installation (secured by the black ring), the closer the focal point (approx. 1 meter). Adjust until the red dot is smallest and sharpest.

6. Long-range focusing: Insert the lens fully. Place the device steadily, aim at a distant cardboard box, and hold the switch for 3 seconds to see the effect.

7. For precise spot size, use a phone camera to zoom in and adjust based on the observed spot.

Our laser cannon can penetrate transparent glass to damage objects behind it, but it can’t shoot at mirrors. Also, the laser’s effect weakens on white or light-colored objects.

✅Currently, we solely offer customs clearance and duty payment services via (home delivery) for the following countries and regions: (EU, Southeast Asia, UK, USA, Canada, Australia, New Zealand, Russia, India, Mexico, UAE, Taiwan, and Hong Kong).

—-Many of our followers complain about the high prices of our machines, unaware that those in countries not on our list, despite having ample funds, are unable to place orders due to customs complications. Therefore, count yourself fortunate that the transportation companies in your country are capable of handling customs formalities.

Transportation and estimated delivery timeframe: Small packages are shipped globally via air freight directly to your doorstep, with a typical delivery duration of 15-20 days to most destinations (Please note, as this is a handmade DIY product, it requires a customization period of 3-5 days prior to shipment).
